Digital Measuring Profile Projector For Wide industries

Digital measuring profile projector Optical Comparators Optical vertical profile projector Features: CPJ-3000/3000Z series digital measuring projector is compact in structure, simple and beautiful in appearance, economical and practical, and reliable. It can effectively measure and compare workpieces directly, such as stamping parts, gears, threads, tools, etc.It is widely used in machinery manufacturing, electronics, moulds, instruments and clocks and other industries. Technical parameters:   Digital Measuring Profile Projector  Model Reverted image Positive image CPJ-3007 CPJ-3007Z CPJ-3010 CPJ-3010Z CPJ-3015 CPJ-3015Z X Axis stroke (mm) 75 100 150 YAxis stroke (mm) 50 50 50 Metal table size (mm) 260×152 306×152 340×152 Glass table size (mm) 125×100 175×100 196×96 X,Y Axial coordinate resolution (μm 0.5 indication error  (μm) E1XY=(2.5 L/100) E1XY=(2.5 L/75) E1XY=(3 L/50) Z Axis stroke (mm) 90 (focus) Equipment weight (kg) 120 125 130 Out size (mm) 770×550×1100 770×550×1100 770×550×1100 projection screen Size (mm)                  Diameter   312,use range>300(It’s engraved with meter lines) Rotation range 0~360° Rotational resolution 1′ or 0.01°  Objective magnification times 10× (choose) 20× (choose) 50× (choose) 100× (choose)  object field (mm) Diameter30 15 6 3 Work distance (mm) 77.7 44.3 38.4 25.3 Max measure height (mm) 80 80 80 80 Power: AC 100-240V 50/60Hz, Total power: 400W Contact us to get your quotation now. Category: Profile Projectors Tags: advanced optical video imaging technology, electronic component measurement, micro-component inspection, precision hardware verification, precision testing tool, quality control tool
