Diaphragm Pressure Gauge，High-pressure diaphragm pressure gauge with oil pressure

YTP series diaphragm pressure gauge is composed of a general pressure gauge of different types and an isolator composed of connectors with specific requirements. Through this connection, the general Bourdon tube pressure gauge increases the performance of measuring the pressure of medium with strong corrosion, high temperature, high viscosity or containing solid plankton and easy to solidify. The gate stone pressure gauge is widely used to measure the pressure of fluid medium in the production process of petrochemical, alkali making, chemical fiber, dyeing, chemical, pharmaceutical, steel, food and other industries. Case size 100mm，150mm accuracy ±1.5% Case Material Stainless steel Range  pressure 0~0.1Mpa-60Mpa vacuum-0.1~0Mpa Spring tube material SS316 Movement material Stainless steel Diaphragm material 316SS,HC,Ta,Monel PTFE Coating Threaded connection size  M20*1.5 or 1/2NPT(other on request)  Flange connection size ANSI,JIS,DIN,HG20592-97 Ambient temperature -40~ 70℃ Degree of protection IP55,IP65 Filling working fluid Silicone oil (optional glycerin or fluorine oil) Category: Pressure Gauges Tags: Electric Water Level Gauge, pressure gauge
