Unidirectional Flow Control Valve Throttle Check Valve

Flow control valve using non compensated throttling. The flow is reduced in only one direction (A to A1) for STU valves and in both directions for STB valves, turning the wheel with locking screw right or left. Guarantees excellent mechanical seal with negligible leakage. It has a galvanised steel body. The check valve tapered poppet is in tempered and ground steel. Flow Control Valve Specification: Hydraulic fluid DIN 51524 Mineral oils Material Carbon steel Temperature -25~75℃ Pressure 350 bar Fluid viscosity 10 ÷ 500 mm2/s Category: Hydraulic Valves Tags: check valve, Flow Control Valve
