20g Vertical Injection Molding Machine Semi-Automatic Pneumatic Plastic Extruder 220V

Product name: Vertical injection molding machine Maximum extrusion volume: 20g (generally applicable to 0-15g) Temperature: 0°-350° Working voltage: 220V Power: 500W Nozzle diameter: 3mm Plunger rod diameter: 20mm Injection method: Manual valve Cylinder pressure: 350kg Air pressure requirement: 0.6Mpa-0.8Mpa Stainless steel injection port It is recommended to fill the plunger barrel to 80% or less each time. If too much material is injected, problems such as adhesion between the plunger and the barrel or between the top and the bottom may occur. Theoretical maximum single injection volume: 0-15 grams Comfortable handle grip, saving time and effort. Cost saving: This injection molding machine uses a simple manual mold removal method to complete injection molding, and the mold can be replaced, realizing one machine for multiple uses.   For more details, please call us. Categories: Plastic Injection Molding Machines, Plastic Machinery Industry Tags: injection, machines, plastic, plastic injiction molding machines, Plastic Machinery Industry
