Growatt Inverter Solar Inverters 6kw Off Grid Inverter Solar Single Phase SPF6000ES Plus

1.LCD display 3.Charging indicator 5.Function buttons 7. PV1input 9. Generatorinput 11.GND 13. Battery input 15. WiFi/GPRS communication port 17. RS485 communication port (for expansion) 19. Parallel communication ports (PAR-OUT) 21. Dry contact 2.Status indicator 4.Fault indicator 6. PV2input 8. ACinput 10. AC output 12.Power on/off switch 14. USB communication port 16. Circuit breaker 18. BMS communication port(supportCAN/RS485 protocol) 20. Parallel communication ports ((PAR-IN) 22.Current sharing ports  Solar Inverters Datasheet SPF6000ESPlus Battery Voltage 48VDC Battery Type Lithium/Lead-acid Inverter Output Rated Power 6000VA/6000W Parallel Capability Yes, 6 units maximum AC Voltage Regulation (Battery Mode) 230VAC ± 5% @ 50/60Hz Surge Power 12000VA Efficiency (Peak) 93% Waveform Pure sine wave Transfer Time 10ms typical ，20ms Max Solar Charger Maximum PV Array Power 8000W MPPT Range @ Operating Voltage 120VDC ~ 450VDC Number of Independent MPP Trackers/ Strings Per MPP Tracker 2/1 Max. input current per MPP tracker 16A Maximum PV Array Open Circuit Voltage 500VDC Maximum Solar Charge Current AC Charger 100A Charge Current 80A AC Input Voltage 230VAC Selectable Voltage Range 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) Frequency Range Physical Protection Degree 50Hz/60Hz (Auto sensing) IP20 Dimension (W/H/D) 460/395/132mm Net Weight (kgs) Operating Environment 13.5 Humidity 5% to 95% Relative Humidity(Non-condensing) Altitude <2000m Operating Temperature 0°C – 55°C Storage Temperature – 15°C – 60°C Category: Growatt Solar Inverter Tags: Growatt Inverter, Off-grid Inverter, Solar Inverters
