Growatt MOD 10KTL3-X MOD 12KTL3-X MOD 15KTL3-X On Grid Solar Inverter

Solar Inverter Datasheet MOD 10KTL3-X MOD 11KTL3-X MOD 12KTL3-X MOD 13KTL3-X MOD 15KTL3-X Input data (DC) Max PV power (for module STC) 15000W 16500W 18000W 19500W 22500W Max. DC voltage 1100V Start voltage 160V Nominal voltage 580V MPPT voltage range 140V-1000V No. of MPP trackers 2 No. of PV strings per MPP tracker 1 1 1/2 1/2 1/2 Max. input current per MPP tracker 13A 13A 13/26A 13/26A 13/26A Max. short-circuit current per MPP tracker 16A 16A 16/32A 16/32A 16/32A Output data (AC) AC nominal power 10000W 11000W 12000W 13000W 15000W Nominal AC voltage 220V/380V, 230V/400V (340-440V) AC grid frequency 50/60 Hz (45-55Hz/55-65 Hz) Max. output current 16.7A 18.3A 20A 21.7A 25A AC grid connection type 3W N PE Efficiency MPPT efficiency 99.9% Protection devices DC reverse polarity protection Yes AC/DC surge protection Type II / Type II Grid monitoring Yes General data Protection degree IP66 Warranty 5 Years Warranty/ 10 Years Optional MOD 10~15KTL3-X Max. efficiency 98.6% OLED and Touch button Type ll SPDon DC and AC side- String Monitoring AFCl optional Model Height (H) Width (W) Depth (D) Weight MOD 10-11KTL3-X 387mm 425mm 178mm 14kg MOD 12-15KTL3-X 387mm 425mm 178mm 16kg Category: Growatt Solar Inverter Tags: Grid Solar Inverter, Solar Inverter
