Growatt Solar Inverter Plug-And-Play Terminal SPF 6000 ES Plus 6kw Single Phase Off Grid Storage Inverter

Solar Inverter Datasheet SPF 6000 ES Plus Battery Voltage 48VDC Battery Type Lithium/Lead-acid Inverter Output Rated Power 6000VA/6000W Parallel Capability Yes, 6 units maximum AC Voltage Regulation (Battery Mode) 230VAC ± 5% @ 50/60Hz Surge Power 12000VA Efficiency (Peak) 93% Waveform Pure sine wave Transfer Time 10ms typical，20ms Max Solar Charger Maximum PV Array Power 8000W MPPT Range @ Operating Voltage 120VDC ~ 450VDC Number of Independent MPP Trackers/ Strings Per MPP Tracker 2/1 Max. input current per MPP tracker 16A Maximum PV Array Open Circuit Voltage 500VDC Maximum Solar Charge Current 100A AC Charger Charge Current 80A AC Input Voltage 230VAC Selectable Voltage Range 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) Frequency Range 50Hz/60Hz (Auto sensing) Physical Protection Degree IP20 Dimension (W/H/D) 460/395/132mm Net Weight (kgs) 13.5 Operating Environment Humidity 5% to 95% Relative Humidity(Non-condensing) Altitude <2000m Operating Temperature 0°C – 55°C Storage Temperature -15°C – 60°C High efficiency up to 93% Maximum PV up to 500VDC Plug-and-Play terminal for PV port Local WIFI connection Category: Growatt Solar Inverter Tags: Off Grid Storage Solar Inverter, Solar Inverter
