Growatt SPF5000ES Solar off-Grid Energy Storage Inverter Supplier 5kw Off-grid Inverter

Storage Inverter Product Description · Integrated MPPT charge controller · Equalization charging function. · Work with battery or without battery. · Maximum PV input voltage up to 450VDC. · Configurable grid or solar input priority. · Optional WIFI/ GPRS remote monitoring. · Support parallel operation for capacity expansion up to 30kW. · PV and Grid power the load jointly if PV energy unsufficient. · Flexibly schedule the Inverter charging and discharging time. Model SPF 3500ES SPF 5000ES Battery Voltage 48VDC Battery Type Lithium/Lead-acid Inverter Output Rated Power 3500VA/3500W 5000VA/5000W Parallel Capability Yes,6 units maximum AC voltage Regulation(Battery Mode) 230VAC±5%@50/60Hz Surger Power 7000VA 10000VA Efficiency(Peak) 93% Waveform Pure sine wave Transfer Time 10ms typical,20ms Max Solar Charger Maximum PV Array Power 4500W 6000W MPPT Range@Operating Volytage 120VDC-430VDC Maximum PV Array Open Circuit Voltage 450VDC Maximum Solar Charger Current 80A 100A AC Charger Charge Current 60A 80A AC Input Voltage 230VAC Selectable Voltage Range 170-280VAC(For Personal Computers);90-280VAC(For Home Appliances) Frequency Range 50/60Hz Physical Protection Degree IP20 Dimension(W/H/D) 330/485/135mm 330/485/135mm Net Weight 11.5kgs 12kgs Operating Environment Humidity 5% to 95% Relative Humidity Alititude <2000m Operating Temperature 0ºC-55ºC Storage Temperature -15ºC-60ºC Category: Growatt Solar Inverter Tags: Off-grid Inverter, Storage Inverter
