Hot Selling Growatt Inverter SPH 6000TL BL-UP 6kW Single Phase Solar Inverter Hybrid Solar Energy Storage Inverter

Solar Inverter Datasheet SPH3000 SPH3600 SPH4000 SPH4600 SPH5000 SPH6000 DC input data Max. recommended PV power 6600W 6600W 6600W 8000W 8000W 8000W Start voltage 150V Max. PV voltage 550V PV voltage range 120V-550V MPPT voltage range /nominal voltage 150V-550V /360V Max. input current of tracker A/B 12A/12A Number of MPP trackers / strings per MPP tracker 2/1 AC Output Rated AC output power 3000W 3680W 4000W 4600W 4999W 6000W Max. AC apparent power 3000VA 3680VA 4000VA 4600VA 5000VA 6000VA Max. output current 16A 16A 22A 22A 22A 27A Nominal AC output voltage 230V Nominal grid frequency 50/60Hz Power factor at rated power 1 THDI <3% AC output power(Backup) Max. output power 3000W Rated AC output voltage 230Vac Rated AC output frequency 50/60Hz Automatic switchover time <0.5S Battery data Battery voltage range 42~59V Max. charging voltage 58V Max charging and discharging current 66A Max charging and discharging power 3000W Battery type lithium /Lead-acid Deep of discharging 80%DOD/50%DOD Capacity of battery 3~12kWh Efficiency Max. efficiency 97.5% 97.5% 97.5% 97.6% 97.6% 97.7% Euro European efficiency 97.0% 97.0% 97.0% 97.1% 97.1% 97.1% MPPT efficiency 99.5% Protection devices DC switch yes DC reverse polarity protection yes Battery reverse protection yes Output over current protection yes Output over voltage protection yes Ground fault monitoring yes Grid monitoring yes Integrated all – pole sensitive leakage yes Category: Growatt Solar Inverter Tags: Growatt Inverter, Single Phase Solar Inverter
