99.99% HEPA Filter 30m Flange 10Bar Compressed Air Filter

Product Introduction:Compressed Air Filter   Compressed air filters are primarily used to filter impurities such as dust, metal wear dirt, condensate, lubricants, acidic condensate, oil mist, and hydrocarbons from compressed air systems. The filter housing is constructed of high-quality aluminum alloy and carbon steel using advanced processing techniques, and the exterior is electrostatically sprayed with epoxy resin powder. The internal filter element utilizes imported high-efficiency separation media and specialized coagulant materials. Available in a full range of specifications and precision grades, it effectively replaces imported filter elements. Optional accessories include a differential pressure gauge, liquid level gauge, and automatic drain. After years of practical application, this product has proven itself to be a reliable alternative to imported products, meeting the diverse requirements of compressed air purification in various domestic and international applications. Performance Characteristics Expanded flow cross-section reduces pressure drop Housing is made of high-quality aluminum alloy and carbon steel Available in two basic styles: threaded and flanged connections, with air flow direction indicated on the housing for easy installation Advanced surface treatment inside and outside the housing enhances durability and corrosion resistance, extending service life Parameter Table：Compressed Air Filter Min.Inlet Pressure kgf/cm²(bar) 2 3 4 5 6 7 8 9 10 Correction Factor 0.38 0.50 0.62 0.75 0.87 1.00 1.12 1.24 1.37   Contact us to get your quotation now. Category: Air (Steam) Filter Tags: bottom drain valve fluid filter, high-pressure liquid-gas impurity filter, modular industrial filtration system, multi-unit stainless steel fluid filter bank, natural gas processing filter, petrochemical fluid filter, robust stainless steel filter bank
